Robust Overload Capacity in HD2000 Drives: 130% Rated Current for 70 Seconds

  • Robust Overload Capacity in HD2000 Drives: 130% Rated Current for 70 Seconds
  • Robust Overload Capacity in HD2000 Drives: 130% Rated Current for 70 Seconds
  • Robust Overload Capacity in HD2000 Drives: 130% Rated Current for 70 Seconds
  • Robust Overload Capacity in HD2000 Drives: 130% Rated Current for 70 Seconds
  • Robust Overload Capacity in HD2000 Drives: 130% Rated Current for 70 Seconds
Luogo di origine Cina
Marca COENG
Certificazione CE
Numero di modello HD2000-C-10-2
Quantità di ordine minimo 1
Imballaggi particolari Scatola di legno
Tempi di consegna giorni 7-30working
Termini di pagamento L/C, T/T, Western Union
Capacità di alimentazione 20000SETS/YEAR

Contattimi gratis campioni e buoni.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

Se avete di preoccupazione, forniamo la guida in linea di 24 ore.

x
Dettagli
Dispositivi mono/multi Sistema flessibile con unità/armadi che supportano due/quattro quadranti Design modulare Consente la flessibilità delle applicazioni e l'integrazione completa del sistema
Unità di rettificatore Unità di raddrizzatore PWM di base/intelligente per la conversione versatile di potenza Max. Potenza per singola unità 1400kW ( raffreddato ad aria), 2800kW (raffreddato a liquido)
Livelli di tensione 400V, 690V, 1140V, 1380V Potenza di funzionamento parallelo massima 11200kW (raffreddato ad aria), 22400kW (raffreddato a liquido)
Evidenziare

VFD drive with overload capacity

,

variable frequency drive 130% current

,

HD2000 drive 70 seconds performance
Lasciate un messaggio
Descrizione di prodotto
ModelHD2000 Series Low Voltage Engineering Inverter(Liquid-cooled)
Basic RectifierInput voltage4:380V～480V,6:500V～690V
Input frequency(50Hz/60Hz)±6%
Output voltageInput voltage * 1.32 (Under full-load condition)
Overload capacityRelative overload at 150% of rated current for 60 seconds, maximum current (Imax), DC overload for 5 seconds,duty cycle of 300 seconds
Operating efficiency≥99% Efficiency
Protection eunctionsProtection functions: Overheating protection, soft-start protection, Interlock
protection, and more.
Intelligent rectifierInput voltage4:380V ~ 480V,6: 500V ~ 690V
Input frequency47 ~ 63Hz
Output voltageInput voltage * 1.3 (Under full-load condition)
Overload capacityRelative overload at 150% of rated current for 60 seconds, maximum current (Imax), DC overload for 5 seconds,duty cycle of 300 seconds
Operating efficiency≥98.5% Efficiency
Protection functionsProtection functions: Overheating protection, Overcurrent protection, IGBT pass-through protection, and more
PWM rectifierInput voltage4:380V~480V,6:500V~690V,9:1140V,A:1380V
Input frequency47 ~ 63Hz
Output voltageInput voltage * 1.5 (Under rated conditions)
Overload capacityRelative overload at 150% of rated current for 60 seconds, maximum current (Imax), DC overload for 5 seconds,duty cycle of 300 seconds
Operating efficiency≥98% Efficiency (Including LCL filter unit)
Power factorAdjustable (Factory setting at 1)
Protection functionsProtection functions: Overheating protection, Overcurrent protection, Overload protection, IGBT pass-through protection, and more.
InversionRated Input voltage4:410Vdc～780Vdc,6:550Vdc～1100Vdc,9:1488Vdc～2200Vdc,
A:1488Vdc~2200Vdc
Output voltage0 ~ Rectifier AC input voltage
Output frequency0 ~ 500Hz
Speed rangeV/F:1:50 OLVC:1:200 CLVC:1:1000
Speed stabilityOLVC:0.2% CLVC:0.01%
Speed fluctuationOLVC:0.2% CLVC:0.1%
Starting torqueOLVC:150%(0.5Hz) CLVC:200%(0Hz)
Torque controlV/F: Unsupported OLVC:Supported CLVC: supported
Torque accuracyOLVC:5% CLVC:5%
Torque response timeOLVC:5ms CLVC:5ms
Speed response timeOLVC:100ms CLVC:100ms
Dynamic speed drop equivalentOLVC:0.5%*s CLVC:0.3%*s
Environmental conditionsTemperature-15℃ ~ +40℃ Without derating, +40℃ ~ +55℃ derating applies
Humidity5% ~ 95% Mon-condensing
Altitude≤4000m, Derating applies from 2000m to 4000m
Mechanical dataAnti-vibration performanceComplies with IEC 60721-3-3:2002
Protection levelIP00 / IP20 / IP40
Safety levelComplies with UL 508C-2004
Cooling methodLiquid-cooled
Motor Drive VFD Inverter Typical Applicantion
Robust Overload Capacity in HD2000 Drives: 130% Rated Current for 70 Seconds 0

Robust Overload Capacity in HD2000 Drives: 130% Rated Current for 70 Seconds 1

Robust Overload Capacity in HD2000 Drives: 130% Rated Current for 70 Seconds 2

The distinctive selling points corresponding to different countries or regions
1.Australia
  • Rugged Environmental Adaptation: Functions efficiently in high temperatures (up to 55°C with derating) and dry conditions common in Australian outback mines.
  • High Altitude Operation: Suitable for mining sites at elevations up to 4000m, ensuring consistent performance.
  • Water-Cooled High Power: Liquid-cooled models (160–2800kW) support Australia’s heavy industries like mineral processing.
  • Rapid Dynamic Response: 0.3% dynamic speed drop in CLVC mode enhances control in conveyor and pump systems.
  • Compliance with International Standards: Meets global safety and performance norms, trusted by Australian engineering firms.
2. Russia
  • Extreme Cold Performance: Operates reliably at -15°C without derating, crucial for Russia’s harsh winters.
  • High Power Range: Models up to 3400kW meet the demands of Russia’s oil, gas, and heavy machinery sectors.
  • Robust Overload Handling: 150% overload capacity ensures stability in intermittent high-load scenarios.
  • Advanced Cooling Flexibility: Air and liquid cooling options adapt to both indoor and outdoor installations.
  • Long-Distance Compatibility: Stable output over wide voltage ranges supports remote industrial sites with unstable power.
3. South Africa
  • Voltage Versatility: Handles input from 380V to 690V, accommodating South Africa’s frequent power fluctuations.
  • Efficiency in High Heat: Maintains ≥98% efficiency even in high-temperature environments common in mining and metallurgy.
  • Dust Protection (IP40): Essential for South Africa’s dusty mining and manufacturing sites.
  • Scalable Solutions: Modular design allows easy expansion from single-drive to multi-drive systems as business grows.
  • Cost Savings: High efficiency and reduced maintenance lower total cost of ownership for budget-conscious industries.
4. Mexico
  • Adaptability to Humid Climates: 5–95% humidity tolerance ensures reliability in Mexico’s coastal and tropical regions.
  • Flexible Installation: Compact and standard cabinet sizes (e.g., 400*2200*650mm) fit diverse industrial layouts.
  • High Starting Torque: 200% at 0Hz (CLVC) supports heavy initial loads in automotive and assembly lines.
  • Energy Compliance: Adjustable power factor helps meet Mexico’s evolving energy regulations.
  • Easy Integration: Compatible with both basic and smart rectifier units, simplifying upgrades in existing plants.
5. United Kingdom
  • High Efficiency for Sustainability: ≥99% efficiency supports the UK’s net-zero carbon goals by reducing energy waste.
  • Precision Control: Speed fluctuation as low as 0.1% (CLVC) ideal for high-tech sectors like aerospace and pharmaceuticals.
  • Safety and Standards: Complies with IEC and UL norms, ensuring compliance with UK’s rigorous safety regulations.
  • Compact and Powerful: Air-cooled models up to 160kW save space in urban industrial zones.
  • Multi-Drive Readiness: Supports modular drive systems for flexible automation in smart manufacturing.
